How to pass data from one activity to another in android

This is the tutorial regarding how to pass data or send string from one activity to another in android.

 I have create a application name intent here.

1. MainActivity.java

package com.app.my.intent;

import android.content.Intent;
import android.os.Bundle;
import android.support.design.widget.FloatingActionButton;
import android.support.design.widget.Snackbar;
import android.support.v7.app.AppCompatActivity;
import android.support.v7.widget.Toolbar;
import android.view.View;
import android.view.Menu;
import android.view.MenuItem;
import android.widget.Button;


public class MainActivity extends AppCompatActivity {

    String a="Hello!, Have a nice day";  // I want to pass this string to the another activity
    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);
        Toolbar toolbar = (Toolbar) findViewById(R.id.toolbar);
        setSupportActionBar(toolbar);
        Button click = (Button) findViewById(R.id.button); // Here i have defined the button

        click.setOnClickListener(new View.OnClickListener() {  //Click event on button
            @Override
            public void onClick(View v) {


                Intent intent = new Intent(MainActivity.this, Main2Activity.class); //here defining the intent
                //to pass data from Mainactivity.java to Main2Activity.java
                intent.putExtra("e1", a); // Here putting an extra text in e1
                startActivity(intent); //calling the other activity



            }
        });




        FloatingActionButton fab = (FloatingActionButton) findViewById(R.id.fab);
        fab.setOnClickListener(new View.OnClickListener() {
            @Override
            public void onClick(View view) {
                Snackbar.make(view, "Replace with your own action", Snackbar.LENGTH_LONG)
                        .setAction("Action", null).show();
            }
        });
    }

    @Override
    public boolean onCreateOptionsMenu(Menu menu) {
        // Inflate the menu; this adds items to the action bar if it is present.
        getMenuInflater().inflate(R.menu.menu_main, menu);
        return true;
    }

    @Override
    public boolean onOptionsItemSelected(MenuItem item) {
        // Handle action bar item clicks here. The action bar will
        // automatically handle clicks on the Home/Up button, so long
        // as you specify a parent activity in AndroidManifest.xml.
        int id = item.getItemId();

        //noinspection SimplifiableIfStatement
        if (id == R.id.action_settings) {
            return true;
        }

        return super.onOptionsItemSelected(item);
    }
}

2. content_mail.xml

<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:tools="http://schemas.android.com/tools"
    xmlns:app="http://schemas.android.com/apk/res-auto" android:layout_width="match_parent"
    android:layout_height="match_parent" android:paddingLeft="@dimen/activity_horizontal_margin"
    android:paddingRight="@dimen/activity_horizontal_margin"
    android:paddingTop="@dimen/activity_vertical_margin"
    android:paddingBottom="@dimen/activity_vertical_margin"
    app:layout_behavior="@string/appbar_scrolling_view_behavior"
    tools:showIn="@layout/activity_main" tools:context=".MainActivity">

        <Button
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:text="Click Me"
        android:id="@+id/button"
            android:layout_marginTop="143dp"
            android:layout_alignParentTop="true"
            android:layout_centerHorizontal="true" />
</RelativeLayout>

  • Now here we are creating the another activity.

3. Main2Activity.java

package com.app.my.intent;

import android.content.Intent;
import android.os.Bundle;
import android.support.design.widget.FloatingActionButton;
import android.support.design.widget.Snackbar;
import android.support.v7.app.AppCompatActivity;
import android.support.v7.widget.Toolbar;
import android.view.View;
import android.widget.TextView;
import android.widget.Toast;

public class Main2Activity extends AppCompatActivity {

    String e1; //defined an string variable e1
    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main2);
        Toolbar toolbar = (Toolbar) findViewById(R.id.toolbar);
        setSupportActionBar(toolbar);
        TextView tv = (TextView) findViewById(R.id.inte); //defined textview
        Intent intent =getIntent(); // code to get data from previous activity
        e1= intent.getStringExtra("e1"); // storing the data in variable e1
        tv.setText(e1);// setting the data to be displayed in textview
        Toast.makeText(getApplicationContext(), e1, Toast.LENGTH_LONG).show();//also displaying as a toast

        FloatingActionButton fab = (FloatingActionButton) findViewById(R.id.fab);
        fab.setOnClickListener(new View.OnClickListener() {
            @Override
            public void onClick(View view) {
                Snackbar.make(view, "Replace with your own action", Snackbar.LENGTH_LONG)
                        .setAction("Action", null).show();
            }
        });
        getSupportActionBar().setDisplayHomeAsUpEnabled(true);
    }

}

4. content_main2.xml

<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:tools="http://schemas.android.com/tools"
    xmlns:app="http://schemas.android.com/apk/res-auto" android:layout_width="match_parent"
    android:layout_height="match_parent" android:paddingLeft="@dimen/activity_horizontal_margin"
    android:paddingRight="@dimen/activity_horizontal_margin"
    android:paddingTop="@dimen/activity_vertical_margin"
    android:paddingBottom="@dimen/activity_vertical_margin"
    app:layout_behavior="@string/appbar_scrolling_view_behavior"
    tools:showIn="@layout/activity_main2" tools:context="com.app.my.intent.Main2Activity">

    <TextView
        android:id="@+id/inte"
         android:layout_width="wrap_content"
        android:layout_height="wrap_content" />

</RelativeLayout>

Here you can see the video tutorial, for viewing that how things goes with output.


You can download full source code for the above tutorial from the below link

Learn and stay tuned and subscribe to my channel "Srce Cde." for more fun.
